| DRYER PROGRAMS |
| Manual Dry Times |
60 min., 40 min., 20 min., More Time/Less Time |
| Drying Levels |
Very, More, Normal, Less, Damp |
| Temperature Settings |
High, Medium, Low |
| Options |
More Time, Less Time, Damp Dry Signal, Wrinkle Care, Control Lock, Energy Saver, Signal |
| No. of Options |
7 |
| Programs (Sensor Dry) |
Normal, Heavy Duty, Bedding, Towels, Perm Press, Delicates, Speed Dry (Manual Dry), Air Dry (Manual Dry) |
| No. of Programs |
8 |
| UPC CODES |
| WM3400CW |
048231027922 |
| DLE3400W |
772454073168 |
| SUMMARY |
| Colours |
White (W) |
| Sensor Dry |
Yes |
| Matching Washer |
WM3400CW |
| Capacity |
7.4 cu. ft. |
| Type |
Front Load Dryer |
| Series |
LG |
| Options |
| Pedestal (WxHxD) |
27 x 14 1/8 x 30 3/4 (50 1/2 D with door open) |
| Pedestal |
WDP4W |
| Stacking Kit |
KSTK1 |
| POWER SOURCE |
| Type |
Electric |
| Electrical Requirements |
240V, 30 Amps |
| Ratings |
CSA Listed |
| Warranty |
| Parts & Labour |
1 Year |
| Dimensions |
| Weight (Carton) |
135.2 lb |
| Weight (Product) |
122 lb |
| Carton (WxHxD) |
29 19/32" x 43 3/8" x 31 3/8" |
| Depth with Door Open |
51" |
| Product (WxHxD) |
27" x 38 11/16" x 30" |
| MATERIALS AND FINISHES |
| All Available Colours |
White (W) |
| Door |
Round with White Painted Trim |
| Cabinet |
Painted Steel |
| Tub Rear |
Painted |
| Aluminized Alloy Steel Drum |
Yes |
| CONVENIENCE FEATURES |
| Smart DiagnosisTM |
Yes |
| Remaining Time Display/Status Indicator(s) |
Yes |
| 4 Adjustable Legs |
Yes |
| Venting Option |
4 Way Venting |
| Child Lock |
Yes |
| Wrinkle Care Option |
Yes |
| FlowSense™ Duct Clogging Indicator |
Yes |
| Reversible Door |
Yes |
| End of Cycle Signal |
Yes |
| LoDecibel™ Quiet Operation |
Yes |
| 3 Minute Installation Check |
Yes |
| Energy |
| CEF |
3.94 |
| ENERGY STAR |
Yes |
| FABRIC CARE FEATURES |
| Precise Temperature Control with Variable Heater |
Yes |
| Sensor Dry |
Yes |
| Appearance |
| Touch Buttons |
Yes |
| Dial-A-Cycle™ |
Yes |
| Intelligent Electronic Controls with LED Display |
Yes |
